RECHARGING
Here you can view how to safely recharge all saber configurations. All users should read through this section to avoid accidentally damaging the soundboard.
An audio clip saying “Sound Energy Critical” will play during blade ignition.
Neo Proffie / Proffie 2.2 Saber
An audio clip saying “Low Battery” will play and prevent blade ignition.
Step 1
Unscrew the pommel and slide out the Power/Shorto Core.
Notice
For easy access, the Power/Shorto Core is designed to slide out smoothly from the bottom of the saber hilt. To avoid any accidental drops, tilt the saber's bottom upwards when removing the pommel.
Toggle the killswitch to OFF.
Attach the provided dust caps to both ends of the Power/Shorto Core to protect the contact pads and speaker.
Step 2
Locate the USB-C port on the Power/Shorto Core.
Pull the prong of the provided USB charger out.
Connect the provided cable's USB-A plug to the port of the USB charger.
Plug the USB charger into a socket.
Connect the cable's USB-C plug to the USB-C port.
Connect the provided smart charger to an outlet with the appropriate adaptor.
Step 3
While charging, the LED indicator on the side of the Power/Shorto Core will be RED.
The battery will take approximately 4~5 hours to charge.
Notice
The charging process will emit some heat. Ensure that the entire charging setup is in a space with adequate airflow.
While other USB-C cables will likely work, we recommend using the provided USB charger and cable.
Step 4
The LED indicator on the charger will turn GREEN once charging is complete.
Disconnnect the USB-C plug.
Remove both dust caps.
Toggle the killswitch to ON.
Slide the Power/Shorto Core back in, ensuring that you do not press the speaker.
Reattach the pommel to secure the chassis inside the hilt.
Notice – Enabling OLED Display
For saber hilts equipped with an OLED screen, the display must be manually enabled each time the Power Core is switched on and reinserted.
To do this, press and hold the aux switch until you hear the first beep, then release it. The saber will reboot and the OLED display will be enabled.
Legacy Recharging Guide
Low Battery Indicators
Neo CFX Saber
An audio clip saying “Sound Energy Critical” will play during blade ignition.
FX Saber
An audio clip saying “Low Battery” will play and prevent blade ignition.
Step 1
Unscrew the pommel.
Slide out the chassis and toggle the killswitch to OFF.
Notice
You will feel some resistance due to the tension created by the wires bundled behind the chassis.
Step 2
Locate the recharge port on the chassis.
Plug the provided smart charger into a socket with the appropriate adaptor.
The LED indicator on the smart charger will light up if it is receiving power.
Connect the smart charger's 2.1mm plug to the chassis' recharge port.
Step 3
While charging, the LED indicator on the smart charger will turn RED.
A full charge requires approximately 4~5 hours.
Notice
The charging process will emit some heat. Ensure that the entire charging setup is in a space with adequate airflow.
We strongly recommend using the provided smart charger only, which has an output of 4.2V, 1.0A.
Step 4
The LED indicator on the smart charger will turn GREEN once charging is complete.
Disconnnect the 2.1mm plug.
Toggle the killswitch to ON.
Slide the chassis back in, ensuring that you do not press the speaker.
Reattach the pommel to secure the chassis inside the hilt.
Stunt Saber Recharging Guide
When the battery is low, the blade will gradually become dimmer and will eventually not illuminate at all.
Step 1
Unscrew the pommel.
Slide out the chassis and toggle the killswitch to OFF.
Notice
You will feel some resistance due to the tension created by the wires bundled behind the chassis.
Step 2
Locate the recharge port on the chassis.
Plug the provided smart charger into a socket with the appropriate adaptor.
The LED indicator on the smart charger will light up if it is receiving power.
Connect the smart charger's 2.1mm plug to the chassis' recharge port.
Step 3
While charging, the LED indicator on the smart charger will turn RED.
A full charge requires approximately 4~5 hours.
Notice
The charging process will emit some heat. Ensure that the entire charging setup is in a space with adequate airflow.
We strongly recommend using the provided smart charger only, which has an output of 4.2V, 1.0A.
Step 4
The LED indicator on the smart charger will turn GREEN once charging is complete.
Disconnnect the 2.1mm plug.
Toggle the killswitch to ON.
Slide the chassis back in.
Reattach the pommel to secure the chassis inside the hilt.
